Hot Racing TRA Steel Spur Gear, 56T 0.8 Mod, Blue

About this part

Hot Racing 56 tooth, 32 pitch (0.8 mod) steel spur gear in blue. It is made for the 1/10 TRA E-Revo, Jato 3.3, T-Maxx 3.3, T-Maxx 2.5R, and Summit.

Features

• CNC machined and lightened hardened steel
• Black oxide coating for durability and corrosion resistance
• Blue anodized countersunk washers

Includes

• One 56 tooth 32 pitch spur gear
• Three mounting screws
• Three blue anodized countersunk washers
• Three washers, to place under the countersunk washers if the screw ends stick through the spur mounting plate

Specifications

• Teeth: 56
• Pitch: 32 (0.8 module)
• Mounting holes: 3
• Tooth face width: 6mm (0.24 inch)
• Inside diameter: about 11mm (about 0.43 inch)
• REQUIRES:
• A hardened clutch bell or pinion gear
• A slipper transmission. This gear will NOT work with a center gear differential. Use Hot Racing SSLF2 series gears for vehicles with a center gear differential.
• FITS:
• Traxxas Jato 2.5 and Jato 3.3
• Traxxas T-Maxx Classic 4910
• Traxxas E-Revo 5603 5605 5608
• Traxxas Summit
• Traxxas T-Maxx 3.3 4907

Fits
