Hot Racing Hex Hub Adapters, 12mm to 17mm, 6mm Offset

About this part

Hot Racing aluminum hub adapters that convert 12mm hex hubs to 17mm hex wheels. Each side of the vehicle gets a 6mm width extension, for a wider and more stable stance. They suit many 1/10 scale vehicles with factory 12mm hex hubs.

Features

• CNC machined solid billet aluminum
• 12mm to 17mm hex conversion
• 6mm offset per side
• Includes 17mm wheel nuts
• Adapters are anodized silver. Wheel nuts are anodized black.
• Wheel nuts have an internal o-ring to keep their position under severe conditions.
• IN THE PACKAGE:
• Four wheel adapters
• Four wheel nuts
• Four M4 axle hub nuts

Requirements

• A removable-type locking adhesive is recommended on the axle nuts.
• The hex should be at least 5mm thick, or the adapter may bind against the hub.

Specifications

• Total length: 20mm
• Maximum axle diameter: 5mm
• Axle thread: M4
• Hex depth: 5mm

Notes

• Replacement M4 axle hub nuts: Hot Racing RSSLF117X.
• O-rings are 11 x 1mm.
