Hot Racing Axial SCX30 Adjustable Damper, 25mm

About this part

A 25mm adjustable spring compression damper set from Hot Racing for the Axial SCX30 and other custom rock crawler builds. These are friction dampers rather than oil-filled units.

Features

• CNC machined T6 aluminum shock bodies
• Precision machined stainless steel shock shafts for durability
• Friction shock mechanism, not oil-filled
• Three spring rates included
• Hard anodized for durability, corrosion resistance, and appearance

You will receive

• Four (4) assembled shocks
• Four (4) silver springs, soft (13 turns)
• Four (4) black springs, medium (12 turns)
• Four (4) gold springs, firm (11 turns)
• Mounting hardware

Requirements

• Installation on the vehicle is required
• SPL10G08 is recommended for smoother action

Specifications

• Extended center to center length: 24.5mm
• Compressed center to center length: 18mm
• Overall length: 29mm
• Body diameter: 3.85mm
• Shaft diameter: 1.5mm

Notes

• To change to a different spring, first remove the cap and spring adjuster. This step matters for a smooth installation. Do not try to remove the shock end for this process.

Fits
