Hot Racing Black Aluminum Air Shocks, Internal Spring, 125mm

About this part

Hot Racing's 125mm internal spring shock set is built for Axial or other custom rock crawler projects.

Features

• CNC machined aluminum bodies, black anodized
• CNC machined aluminum lower caps with shock shaft guides, silver anodized
• Precision machined 6mm stainless steel shafts
• Delrin lower shaft seals
• Air damping
• Internal springs in two rates: black (stiff) and silver (medium)
• Anodized aluminum for durability, corrosion resistance and appearance

You will receive

• Two assembled shocks
• Two black (stiff) springs and two silver (medium) springs
• Four 4.8mm ball mounts
• Four 3 x 12mm cap head screws
• Eight 6mm OD O-rings
• Two M3 lock nuts

Requirements

• Installed on the vehicle. SPL10G08 is recommended for smoother action.

Specifications

• Extended center to center: 125mm (4.92 in)
• Compressed center to center: 85mm (3.35 in)
• Overall length: 133mm (5.2 in)
• Body diameter: 11mm (0.43 in)
• Shaft diameter: 6mm (0.24 in)
• Fits Axial AX-10 Deadbolt, AX-10 Ridgecrest Crawler, RR-10 Bomber, SCX-10 II, SCX-10 II 6 wheel and SCX-10 II Deadbolt.
